IP65 Stainless Steel Sheel Glass Cover Explosion Proof Luminaire LED Tunnel Light
Description of Stainless Steel Explosion Proof Lights:
Housing: Stainless steel
Diffuser: Tempered glass(clear or frosted) 60 90 120 Beam Angle
Other characteristics: pollution free,low power consumption, high luminous efficiency & IP65;
High-low impact, high humidity environmental tests
Features:
* Suitable for extreme temperatures & high humidity outdoor environments;
* Resistance to impact, seismic activities,and strong ultraviolet & infrared radiation;
* Over 70% energy savings compared to conventional lights with similar lumen output;
* Provides 50,000 hours lifetime & 5 years warranty
Stainless Steel Explosion Proof Luminaire Lights data sheet :
| Technical Paramenters (Test Conditions:25℃/55-%60%Humidity) |
| Item Code | MF-SS-25W-600 | MF-SS-35W-1300 | MF-SS-50W-130 | MF-SS-45W-1600 | MF-SS-65W-1600 |
| Power(W)+/-10% | 25W | 35W | 50W | 45W | 65W |
| Input Voltage/Frequency | AC 220-240V 50/60Hz |
| Installation | Easy and quick to install under celling or on surface |
| Housing/Diffuser | 304 stainless steel housing,Tempered glass diffuser. |
| Driver | Osram / Meanwell / Tridonic / Chinese local brand |
| LED Brand | SMD2835 / SMD3030 |
| CCT | 2700-6500K (ANSI C78.377) |
| CRI | > 80 |
| 5000K/Opal Diffuser Light Output(+/- 3%) | 3,500 lm | 4,900 lm | 7,000 lm | 6,300 lm | 8,680 lm |
| Power factor | PF>0.9 |
| Beam Angel | 90° / 120° |
| IP Rating | IP65 |
| Warranty | 5 Year |
| Operating temp range | -20°~40° |
| Clips Qty (pcs) | 6 | 10 | 10 | 12 | 12 |
| Product Size (mm) | 670*110*65 | 1280*110*65 | 1590*110*65 |
130lm/w are workable and 6000K. Clear and frosted Cover are available.
Zone I &II 2G Ex eb mb op is q IIC T4 Gb
Zone I &II 2D Ex tb op is IIIC T80oC Db
Compared with others Tube Lights, our LED Tri-proof light has great advantages as below :
Ming Feng Lighting Produce a superb triproof light which is made of stainless steel sheel and glass cover, this special material and design is frozen room,steel plant and all kinds of warehouse. This triproof LED light can work at temperature of -40°C to +50°, it's an ideal lamp for harsh working conditions.
IP65, 90°/120° beam angle, and 304 stainless steel casing tri-proof lights have many advantages and can be used in various scenarios.
Firstly, the IP65 rating ensures that the light is dust-tight and protected against water jets, making it suitable for outdoor environments.
Secondly, the 90°/120° beam angle allows for a wide coverage area, ensuring that the light can illuminate a larger space.
Additionally, the 304 stainless steel casing is durable and resistant to corrosion and rust, ensuring that the light can withstand harsh environmental conditions.
Overall, these triple-proof lights are a good choice for anyone looking for a durable and reliable lighting solution that can withstand harsh environmental conditions while providing ample lighting.
Product Details:
Size details:
A: 680mm
B: 1300mm
C: 1600mm
Lighting details:
Packing Information :
Using the strong boxes for the package, there is a inner box with a set of lamp. 6 sets of lamp for outer box.
Applications:
These lights are ideal for use in a variety of environments, including industrial facilities, warehouses, parking lots and outdoor areas such as building facades and parks. They are also suitable for use in places where they may be exposed to water or dust, such as swimming pools, construction sites and tunnels.
